Iphone 7 Screw Location Image. - reddit Iphone 7 Screw Location Image. General Help Req. So I've been searching online for an image of all the screw locations. I need to replace the microphone and I've never gone beyond replacing the screen and battery. One thing I'm keen on doing is keeping all the screws organised so when I go to put it all back together I won't have any issues. iPhone 8 Plus Screw Chart | RepairPartsPlus.com iPhone 8 Plus Screw Placement Chart. Makes it easy to keep track of all the parts and screws. Screws are tiny! Don't lose any by adhering to this chart in order. Reduce risk of damage. Screws are not universal or interchangeable so must be put back in original spot.
